Live 2022.09.04

Solaris Karma MaterialX Surface Shader Blending

Scene File

Summary

This stream covers importing MaterialX files into Solaris, how they can be modified and finally how to mix multiple surface shaders to produce gold flakes embedded in marble.

Reference images of gold flakes embedded in quartz and other rocks.

Example materials that ship with MaterialX and can be found in the Houdini install directory:

$HH/materialx/resources/Materials/Examples/StandardSurface/

Materials downloaded from Ambient CG contain .usd files which can be imported into Solaris using a reference LOP.

The blending of surface shaders is controlled by a spatial noise visualized below, this mask drives the mixing and blending between marble and gold.

Video On Demand

02:35 Importing the MaterialX Shaderball
03:59 MaterialX online viewer
05:51 Importing shaderball geometry from SOP network into Solaris
06:38 Viewing the Solaris scene graph tree
10:10 Using materials from https://ambientcg.com/
23:05 Autodesk Standard Surface Documentation
25:45 Duplicating geometry
28:00 Editing a material MaterialX graph
35:10 Importing the marble material
39:17 Edit material properties LOP
43:30 Editing the marble shading network
53:00 Mixing surface nodes
58:00 Using spatial noise to mix surfaces
1:11:00 usdz files documentation
1:14:00 Wrapping up, stream topics overview
